Stainless Steel Ball Valve 3PC Fire Safe, NPT Threaded

Liên hệ



Van Bi Inox 3 Mảnh INOX Nối Ren NPT

Vật liệu: Thân - Inox, Bi - INOX, Vòng đệm PTFE
Lắp đặt: Ren NPT
Ứng dụng: Khí nén, Hơi nóng, Xăng dầu, Gas,...

Stainless Steel Ball Valve 3PC Fire Safe, NPT Threaded

Van Bi Inox 3 Mảnh Chống Cháy Nổ Nối Ren NPT

2 way 3 piece full bore investment cast 316 stainless steel ball valve with lockable lever and solid ball. ISO5211 mounting pad, length to DIN 3202-M3. Fire Safe approved certificate number 249036.



FEATUERS

Size 1/2" to 4" NPT
Body 316 Stainless Steel
Seat PTFE
Pressure 130 Bar
Temperature -20°C to 180°C
Actuation Lockable Lever
Fire Safe API607 Approved



CẤU TẠO

Item Part Material Qty
1 Cap CF8M 1
2 Body CF8M 1
3 Ball SS316 1
4 Ball Seat Pure PTFE 2
5A Body Gasket A Pure Graphite 1
5B Body Gasket B Pure Graphite 1
6 Thrust Washer Pure PTFE 1
7 Stem SS316 1
8 O-ring Viton 1
9A Stem Packing A Pure Graphite 1



Item Part Material Qty
9B Stem Packing B Pure Graphite 1
10 Gland SS304 1
11 Bellevlle Washer SS301 2
12 Nut Stopper SS304 1
13 Plate Washer SS304 1
14 Nut SS304 2
15 Handle SS304 1
16 Bolt SS304 4
17 Handle Cover Plastic 1
18 Stop Pin SS304 1
